• Hoskins H9-14D heated pig waterer, 28 by 14 in. stainless tank in a galvanized frame
1 1

Hoskins H9-14D Heated Pig Waterer, 9 in. Frame – 5 Gallon

Hoskins H9-14D Heated Pig Waterer, 9 in. Frame – 5 Gallon

Part Number H914D

$690.00 USD
$690.00 USD
Sale Sold out
Shipping calculated at checkout.

Twenty-eight inches long, 14 in. wide, 9 in. tall, two compartments, 5 gallons. Rated up to 100 head.

What you are getting

  1. Stainless steel tank, 5 gallons (19 litres)
  2. Overall 28 in. long by 14 in. wide by 9 in. tall
  3. Insulated galvanized steel frame, 60 lb. empty
  4. One Model A element, 250 watts total, held off the tank
  5. 3/8 in. RM 153
  6. 1 1/2 in. rubber stopper on the drain
  7. Two drinking compartments
  8. Rated for up to 100 hogs

The model number is the spec

Nine is the height. Fourteen is the width. D is two compartments. Every model in the H9 series reads the same way.

How Hoskins builds them

A H9-14D is a stainless tank of 5 gallons sitting inside a 16 gauge galvanized shell, with insulation between them and the Model A element carried in the shell rather than bolted to the tank.

The RM 153 float-and-valve assembly, 3/8 in., sits in an insulated compartment of their own behind a lift-off cover, so a repair in January does not mean emptying the tank. The drain stopper is 1 1/2 in..

This one measures 14 in. across the body and stands 9 in. deep, carrying two compartments. Galvanized frame, 60 lb. empty.

Putting one in

The water line and the power both come up inside the base of a H9-14D, so one trench carries both and the stub-ups have to land inside a 28 by 14 in. footprint. Set a reinforced pad roughly 36 by 22 in. and stand it a few inches above the ground around it, which keeps muck from packing against the frame.

Electrically the Model A element pulls 2.1 amps on 120 volts, so its own 15 amp circuit is enough. Ask whoever wires it to confirm the earth at the same visit. Stray voltage is the usual reason stock go off a waterer that is working perfectly well, and it is almost never the first thing anyone checks.

Read your water pressure at the unit rather than at the well, and read it more than once in a day. At 60 lb. empty two people can set this one, which is part of why it ships by UPS. Hoskins puts the rating at up to 100 hogs.

Browse the rest of the line under Hoskins pig waterers, or see Hoskins waterer parts.

View full details

More about the H9-14D

Parts the H9-14D takes

Valve: 3/8 in. RM 153 (no separate float rod on this model). Drain stopper: 1 1/2 in.. Heating element: Model A, 250 watts at 120 volts.

Every one of those is a stock item here. The full list for this model is in the collection further down the page.

Shipping and pick-up

At 60 lb. the H9-14D goes out by UPS ground, the same way a box of parts does, so there is no freight quote to wait on.

Pick-up at Hoskins, NE is available if you would sooner collect it.

Dimensions and weight

Overall 28 in. long by 14 in. wide by 9 in. tall. Tank capacity 5 gallons. Weight empty 60 lb.

Allow a pad a few inches wider than the frame on every side, standing above the surrounding ground so muck does not pack against it.

Keeping it running

Flush the tank weekly through the cold months and check that the 1 1/2 in. stopper is seating on clean rubber. The 3/8 in. RM 153 assembly is the one wearing part worth a spare.

If stock suddenly go off a waterer that is working, check the ground at the breaker box before anything else. Stray voltage puts animals off water and nothing looks wrong.

Need Parts for your Hoskins H9-14D?

The parts that fit a Hoskins H9-14D, gathered in one place so you are not reading a spec sheet in a cold valve compartment.

This model takes the 3/8 in. RM 153 valve and float assembly, which needs no separate rod, a 1 1/2 in. rubber stopper, and the A250 element. Valve, rod and stopper all sit behind the same service door, so if one is coming out it is worth checking the others while the cover is off.
